Circuitos Integrados Smd SG2524 PWM

SG2524

Regulador PWM

I.C. SMPS

I.C. para Fuentes conmutadas, Step-Up/Down

Encapsulado Smd SO16 y Dip16

Descargar PDF

SG2524 SMPS control circuit, This monolithic integrated circuit contains all the control circuitry for a regulating power supply inverter or Switching Regulator Included in a 16-pin dual-in-line package is the Voltage Reference error Amplifier Oscillator pulse-width Modulator pulse steering Flip-Flop dual alternating output switches and current-limiting and shut-down circuitry. This device CAN be used for Switching Regulators of either polarity, transformer-coupled DC-to-DC converters, transformerless Voltage doublers and polarity converters, as well as other power control applications. The SG2524 is designed for commercial applications of 0C to +70C.
